● Up to 12,000 hours laser Life , French press key with life of 8 million pressing times .

● Application fields:Supermarket, Retail, Warehouse,Logistic,Library, Medical etc.

● Can be customized according to customer demand.

Technical parameters

Electrical parameter : 5/3.3 V ± 10%x100mA (idle:10mA)

Scanning type : bi-directional

CPU : ARM 32-bit Cortex

Light source : 650 nm visual laser diode

Trigger Mode : Handheld,Continuous,Auto-Induction

Indication : Buzzer & LED

Printing Contract : >25%

Resolution : 3.3mil

Decoding speed : 300scans/sec

Bit error rate : 1/5millon,1/20million

Scanning width : 30cm

Depth of Field : 3.3mil 2mm-100mm,10mil 2mm-350mm,15.6mil 5mm-600mm,35mil 10mm-1000mm

Scanning angle : rotor angel±30°,inclination± 45°,declination ± 60°

Anti inference : industrial lighting or sun will not make any difference

Decoding Capability : UPC/EAN,with complementary UPC/EAN Code128,Code39,Code 39Full,ASCII,Coda bar,industrial/Interleaved2 of 5,

Code93,MSI,Code11, ISBN,ISSN,China post,etc

Button life : 8000,000 times ; laser life:12000 hours

Drop test : 2.0m fall to concrete

Interface : TTL,RS232,KBW,USB

Certificate : CE,FCC,ROHS,IP54,FDA,SGS

Packaging Details

Standard List: Scanner*1, USB Cable *1,Manual *1, Stand * 1, Box *1.

Single Package Size: 185*120*86mm

Single Gross Weight: 0.45kg

30pcs/CTN Carton Size: 438*380*380mm

30pcs/CTN Carton G.W.:14Kg, N.W:11Kg

Shenzhen Yuhengda Technology Co., Ltd(YHDAA) is one of the leading and professional barcode scanner and thermal printer manufacturers in China. YHDAA focus on barcode read technology with over 10 years of experience in barcode scan and print technology industry area.

YHDAA products include 1D&2D barcode scanner,laser and CCD barcode scanner,wireless barcode scanner, barcode scanner module,scan engines,omnidirectional scanning platform, thermal printer etc. YHDAA products have been widely used in logistic, supermarket,retailing, medical,postal communication, office automation,manufacturing etc. All products are certificated by CE,FCC,RoHS,IP54,FDA,RF etc.

We have our own R&D department, Quality Control department,sale and after-sale department. As a barcode scanner manufacturers,We have full set of hi-tech testing equipment,also with strictly management and process on production.we support the OEM and ODM orders, No matter who you are, an end-user, a trader, a software integrator, a branding hardware distributor, we are deeply convinced that you can find cost effective products with high performance.

We have exported our products to America, Canada, Europe, India, Turkey,Russia, UK,Indonesia, and more than 100 countries with more than 10,000 customers.

YHDAA insists on the business principle of "Quality First, Credit Utmost",and YHDAA does the best to be your reliable business partner.,Facing the global market, we will follow the trends, growing and benefiting together with our customers and We will offer customers high quality products at competitive prices.

Welcome to China visit our factory!
